Size/Weight |
---|
Dimensions | Width | 1,430 mm (56-5/16") | 1,426 mm (56-1/8") (Polished finish: 1,429 mm (56-1/4")) | 1,420 mm (55-15/16") (Polished finish: 1,423 mm (56-0")) |
---|
Height | 913 mm (35-15/16") | 868 mm (34-3/16") (Polished finish: 872 mm (34-5/16")) | 868 mm (34-3/16") (Polished finish: 871 mm (34-5/16")) |
---|
Depth | 1,236 mm (48-11/16") | 612 mm (24-1/8") (Polished finish: 612 mm (24-1/8")) | 592 mm (23-5/16") (Polished finish: 593 mm (23-3/8")) |
---|
Weight | Weight | 130 kg (286 lb, 10 oz) | 82 kg (180 lb, 12 oz) (Polished finish: 85 kg (187 lb, 6 oz)) | 82 kg (180 lb, 12 oz) (Polished finish: 84 kg (185 lb, 3 oz)) |
---|
Packing Box | Width | 1,570 mm (61-13/16") | 1,567 mm (61-11/16") | 1,551 mm (61-1/16") |
---|
Height | 620 mm (24-7/16") | 716 mm (28-3/16") | 708 mm (27-7/8") |
---|
Depth | 1,410 mm (55-1/2") | 745 mm (29-5/16") | 736 mm (29") |
---|
Control Interface |
---|
Keyboard | Number of Keys | 88 | 88 | 88 |
---|
Type | GrandTouch Keyboard: wooden keys (white only), synthetic ebony and ivory key tops, escapement | GrandTouch Keyboard: wooden keys (white only), synthetic ebony and ivory key tops, escapement | GrandTouch Keyboard: wooden keys (white only), synthetic ebony and ivory key tops, escapement |
---|
Touch Sensitivity | Hard2/Hard1/Medium/Soft1/Soft2 | Hard2/Hard1/Medium/Soft1/Soft2 | Hard2/Hard1/Medium/Soft1/Soft2 |
---|
88-key Linear Graded Hammers | Yes | Yes | Yes |
---|
Counterweight | Yes | Yes | - |
---|
Pedal | Number of Pedals | 3 | 3 | 3 |
---|
Half Pedal | Yes | Yes | Yes |
---|
GrandTouch Pedals | Yes (with GP Response Damper) | Yes (with GP Response Damper) | Yes |
---|
Functions | Sustain, Sostenuto, Soft, Glide, Song Play/Pause, Style Start/Stop, Volume, etc | Sustain, Sostenuto, Soft, Glide, Song Play/Pause, Style Start/Stop, Volume, etc | Sustain, Sostenuto, Soft, Glide, Song Play/Pause, Style Start/Stop, Volume, etc |
---|
Display | Type | TFT Color LCD (Touch Screen) | TFT Color LCD (Touch Screen) | TFT Color LCD (Touch Screen) |
---|
Size | 800 × 480 dots 9.0 inch | 800 × 480 dots 9.0 inch | 800 × 480 dots 7.0 inch |
---|
LCD Brightness | Yes | Yes | Yes |
---|
Touch Screen | Yes | Yes | Yes |
---|
Color | Yes | Yes | Yes |
---|
Score Display Function | Yes | Yes | Yes |
---|
Lyrics Display Function | Yes | Yes | Yes |
---|
Text Viewer Function | Yes | Yes | Yes |
---|
Language | English, German, French, Spanish, Italian, Japanese | English, German, French, Spanish, Italian, Japanese | English, German, French, Spanish, Italian, Japanese |
---|
Panel | Language | English | English | English |
---|
Cabinet |
---|
Key Cover | Key Cover Style | Folding | Folding | Folding |
---|
Music Rest | Yes | Yes | Yes |
---|
Music Clips | Yes | Yes | Yes |
---|
Voices |
---|
Tone Generation | Piano Sound | Yamaha CFX, Bösendorfer Imperial | Yamaha CFX, Bösendorfer Imperial | Yamaha CFX, Bösendorfer Imperial |
---|
Binaural Sampling | Yes (“CFX Concert Grand” and “Bösendorfer Grand” Voice only) | Yes (“CFX Concert Grand” and “Bösendorfer Grand” Voice only) | Yes (“CFX Concert Grand” and “Bösendorfer Grand” Voice only) |
---|
Key-off Samples | Yes | Yes | Yes |
---|
Smooth Release | Yes | Yes | Yes |
---|
Virtual Resonance Modeling (VRM) | Yes | Yes | Yes |
---|
Grand Expression Modeling | Yes | Yes | Yes |
---|
Polyphony | Number of Polyphony (Max.) | 256 | 256 | 256 |
---|
Preset | Number of Voices | 1,605 Voices + 58 Drum/SFX Kits + 480 XG Voices | 1,605 Voices + 58 Drum/SFX Kits + 480 XG Voices | 1,315 Voices + 49 Drum/SFX Kits + 480 XG Voices |
---|
Featured Voices | 17 VRM Voices, 36 Super Articulation2 Voices, 301 Super Articulation Voices | 17 VRM Voices, 36 Super Articulation2 Voices, 301 Super Articulation Voices | 14 VRM Voices, 227 Super Articulation Voices |
---|
Custom | Voice Edit | Yes | Yes | Yes |
---|
Compatibility | XG, GS (for Song playback), GM, GM2 | XG, GS (for Song playback), GM, GM2 | XG, GS (for Song playback), GM, GM2 |
---|
Effects |
---|
Types | Reverb | 65 Preset + 30 User | 65 Preset + 30 User | 65 Preset + 30 User |
---|
Chorus | 107 Preset + 30 User | 107 Preset + 30 User | 106 Preset + 30 Use |
---|
Master Compressor | 5 Preset + 30 User | 5 Preset + 30 User | 5 Preset + 30 User |
---|
Master EQ | 5 Preset + 30 User | 5 Preset + 30 User | 5 Preset + 30 User |
---|
Part EQ | 27 Parts | 27 Parts | 27 Parts |
---|
Intelligent Acoustic Control (IAC) | Yes | Yes | Yes |
---|
Stereophonic Optimizer | Yes | Yes | Yes |
---|
Insertion Effect | 358 Preset + 30 User | 358 Preset + 30 User | 322 Preset + 30 User |
---|
Variation Effect | 358 Preset + 30 User | 358 Preset + 30 User | 322 Preset + 30 User |
---|
Vocal Harmony | 54 Preset + 60 User | 54 Preset + 60 User | 54 Preset + 60 User |
---|
Functions | Dual/Layers | Yes | Yes | Yes |
---|
Split | Yes | Yes | Yes |
---|
Accompaniment Styles |
---|
Preset | Number of Preset Styles | 675 | 675 | 525 |
---|
Fingering | Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard | Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard | Single Finger, Fingered, Fingered On Bass, Multi Finger, AI Fingered, Full Keyboard, AI Full Keyboard |
---|
Style Control | INTRO × 3, MAIN VARIATION × 4, FILL × 4, BREAK, ENDING × 3 | INTRO × 3, MAIN VARIATION × 4, FILL × 4, BREAK, ENDING × 3 | INTRO × 3, MAIN VARIATION × 4, FILL × 4, BREAK, ENDING × 3 |
---|
Custom | Style Creator | Yes | Yes | Yes |
---|
Other Features | Music Finder | Yes | Yes | Yes |
---|
One Touch Setting (OTS) | 4 for each Style | 4 for each Style | 4 for each Style |
---|
Style Recommender | - | - | - |
---|
Chord Looper | Yes | Yes | Yes |
---|
File Format | Style File Format (SFF), Style File Format GE (SFF GE) | Style File Format (SFF), Style File Format GE (SFF GE) | Style File Format (SFF), Style File Format GE (SFF GE) |
---|
Songs |
---|
Preset | Number of Preset Songs | 50 Classics + 303 Lesson Songs + 60 Popular | 50 Classics + 303 Lesson Songs + 60 Popular | 50 Classics + 303 Lesson Songs + 60 Popular |
---|
Recording | Number of Tracks | 16 | 16 | 16 |
---|
Data Capacity | approx. 3 MB/Song | approx. 3 MB/Song | approx. 3 MB/Song |
---|
Recording Function | Yes | Yes | Yes |
---|
Compatible Data Format | Playback | SMF (Format 0, Format 1), XF | SMF (Format 0, Format 1), XF | SMF (Format 0, Format 1), XF |
---|
Recording | SMF (Format 0) | SMF (Format 0) | SMF (Format 0) |
---|
Functions |
---|
Demo | Yes | Yes | Yes |
---|
Registration | Number of Buttons | 8 | 8 | 8 |
---|
Control | Registration Sequence, Freeze | Registration Sequence, Freeze | Registration Sequence, Freeze |
---|
Playlist | Number of Records | 2,500 | 2,500 | 2,500 |
---|
Lesson/Guide | Lesson/Guide | Follow Lights, Any Key, Karao-Key, Your Tempo (with guide lamps) | Follow Lights, Any Key, Karao-Key, Your Tempo (with guide lamps) | Follow Lights, Any Key, Karao-Key, Your Tempo (with guide lamps) |
---|
Guide Lamp | Yes | Yes | Yes |
---|
Performance Assistant Technology (PAT) | Yes | Yes | Yes |
---|
Piano Room | Yes | Yes | Yes |
---|
USB Audio Recorder | Playback | WAV (44.1kHz, 16bit, stereo), MP3 (MPEG-1 Audio Layer-3) | WAV (44.1kHz, 16bit, stereo), MP3 (MPEG-1 Audio Layer-3) | WAV (44.1kHz, 16bit, stereo), MP3 (MPEG-1 Audio Layer-3) |
---|
Recording | WAV (44.1kHz, 16bit, stereo), MP3 (MPEG-1 Audio Layer-3) | WAV (44.1kHz, 16bit, stereo), MP3 (MPEG-1 Audio Layer-3) | WAV (44.1kHz, 16bit, stereo), MP3 (MPEG-1 Audio Layer-3) |
---|
USB Audio | Time Stretch | Yes | Yes | Yes |
---|
Pitch Shift | Yes | Yes | Yes |
---|
Vocal Cancel | Yes | Yes | Yes |
---|
Miscellaneous | Metronome | Yes | Yes | Yes |
---|
Tempo Range | 5 – 500, Tap Tempo | 5 – 500, Tap Tempo | 5 – 500, Tap Tempo |
---|
Transpose | −12 – 0 – +12 | −12 – 0 – +12 | −12 – 0 – +12 |
---|
Tuning | 414.8 – 440 – 466.8 Hz (approx. 0.2 Hz increments) | 414.8 – 440 – 466.8 Hz (approx. 0.2 Hz increments) | 414.8 – 440 – 466.8 Hz (approx. 0.2 Hz increments) |
---|
Scale Type | 9 Types | 9 Types | 9 Types |
---|
Display Out | Yes (by using a commercially available USB display adaptor*) | Yes (by using a commercially available USB display adaptor*) | Yes (by using a commercially available USB display adaptor*) |
---|
Bluetooth | Yes (Audio) | Yes (Audio) | Yes (Audio) |
---|
Storage and Connectivity |
---|
Storage | Internal Memory | approx. 2 GB | approx. 2 GB | approx. 2 GB |
---|
External Drives | USB flash drive | USB flash drive | USB flash drive |
---|
Connectivity | Headphones | Standard stereo phone jack (× 2) | Standard stereo phone jack (× 2) | Standard stereo phone jack (× 2) |
---|
Microphone | Mic/Line in (standard mono phone jack), Input volume | Mic/Line in (standard mono phone jack), Input volume | Mic/Line in (standard mono phone jack), Input volume |
---|
MIDI | IN, OUT, THRU | IN, OUT, THRU | IN, OUT, THRU |
---|
AUX IN | Stereo mini jack | Stereo mini jack | Stereo mini jack |
---|
AUX OUT | L/L+R, R | L/L+R, R | L/L+R, R |
---|
AUX Pedal | Yes | Yes | Yes |
---|
USB TO DEVICE | Yes (× 2) | Yes (× 2) | Yes (× 2) |
---|
USB TO HOST | Yes | Yes | Yes |
---|
Amplifiers and Speakers |
---|
Amplifiers | (40 W + 30 W + 20 W) × 2 + 80 W | (40 W + 30 W + 20 W) × 2 + 80 W | (45 W + 20 W) × 2 |
---|
Speakers | 16 cm + 5 cm + 2.5 cm (dome)) × 2 + 20 cm, Spruce Cone Speaker, Twisted Flare Port | 16 cm + 5 cm + 2.5 cm (dome)) × 2 + 20 cm, Spruce Cone Speaker, Twisted Flare Port | (16 cm + 2.5 cm (dome)) × 2 |
---|
Power Supply |
---|
Power Consumption | 67W | 64W | 52W |
---|
Accessories |
---|
Accessories | Headphones (HPH-150/HPH-100/HPH-50), Footswitches (FC4A/FC5), Foot controller (FC7), USB wireless LAN adaptor (UD-WL01) | Headphones (HPH-150/HPH-100/HPH-50), Footswitches (FC4A/FC5), Foot controller (FC7), USB wireless LAN adaptor (UD-WL01) | Headphones (HPH-150/HPH-100/HPH-50), Footswitches (FC4A/FC5), Foot controller (FC7), USB wireless LAN adaptor (UD-WL01) |
---|
